UL Listed

Suitable for wet locations. Suitable for mounting within 1.2m (4ft) of the ground.

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Driver

Constant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.24A, 208V: 0.14A, 240V: 0.12A, 277V: 0.11A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

7.54% at 120V, 16.25% at 277V

Power Factor

99.1% at 120V, 90.6% at 277V

Note

All values are typical (tolerance /- 10%)

Lens

Soda lime silica clear glass

Housing

Die-cast aluminum housing, lens frame and mounting arm

Mounting

Heavy-duty mounting arm with "O" ring seal & stainless steel screw

IP Rating

Ingress Protection rating of IP66 for dust and water

Maximum Ambient Temperature

Suitable for use in up to 40°C (104°F)

Cold Weather Starting

Minimum starting temperature is -40°C (-40°F)

Effective Projected Area

EPA = 0.65

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Formulated for high durability and long-lasting color

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Consistency

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.

NEMA Type

7H x 6V Beam Spread

Equivalency

Equivalent to 100W Metal Halide
